STREETS AND CURBS EATER

Racing look, 4 valves liquid cooled engine with electronic injection and driving position refined on racetrack allow you to face every situation riding your SMX supermotard with maximum agility. Finding the most winding roads after school or going to racetrack on Sundays will not be a problem for you.

alt=""
Supermotard version. Racing will not be scary for anyone.
The high center of gravity allows better agility both on track and in the traffic jams. After school trip will become the constant research for the narrowest hairpin.
17 inch wheels will help you to test your limits.
11kW! The engine, 4 valves with electronic injection, is one of the few in the world who can grant the maximum power allowed by law for A1 license.

Type Single cylinder, 4 stroke, DOHC, 4 valves
Displacement



124 cm3
Bore x Stroke 58×47 mm
 Compression ratio 12,0:1
 Lubrication Wet sump
 Cooling system Liquido



Liquid
Intake system EFI
 Starting system Electric starter
 Transmission 6 speed
Fuel tank 6,3 L

Front suspension  40 mm Ø 41 mm fork, 247 mm
Rear suspension Single shock Absorber  (270 mm)
Mass in running order 124 kg
Seats 2
Front brake  2 pistons floating caliper  ABS/CBS 300 mm
Rear brake  1 piston floating caliper ABS/CBS 220 mm
 Front wheel 2,50 x 17”
Rear wheel 3,50 x 17”
 Front tyre 100/80 x 17”
Rear tyre 130/70 x 17”
Colors White Red
White Blue

Length 2080 mm
Width 825 mm
Height



1180 mm
Wheelbase 1425 mm
Ground clearance 250 mm
Seating position height 980 mm

Discover SMX Enduro
